    Kingbright AB814B

    Part No.:
    AB814B
    Manufacturer:
    Kingbright
    Category:
    Transistor, Photovoltaic Output Optoisolators
    Package:
    4-DIP (0.300", 7.62mm)
    Datasheet:
    ICMILES ELECTRONICS LIMITEDAB814B.pdf
    Description:
    1-CHANNEL PHOTOCOUPLER LED
    Quantity:

    Unit Price:$0

    Ext Price:$0

    Payment:
    Payment
    Shipping:
    Shipping

    Product details

    • Specifications
    • FAQ
    • Comparison
    Product attributes
    Attribute value
    Manufacturer:
    Kingbright
    Series:
    -
    Package/Case:
    4-DIP (0.300", 7.62mm)
    Packaging:
    Tube
    Product Status:
    Active
    Number of Channels:
    1
    Voltage - Isolation:
    5000Vrms
    Current Transfer Ratio (Min):
    120% @ 1mA
    Current Transfer Ratio (Max):
    300% @ 1mA
    Turn On / Turn Off Time (Typ):
    -
    Rise / Fall Time (Typ):
    4µs, 3µs
    Input Type:
    AC, DC
    Output Type:
    Transistor
    Voltage - Output (Max):
    35V
    Current - Output / Channel:
    50mA
    Voltage - Forward (Vf) (Typ):
    1.2V
    Current - DC Forward (If) (Max):
    50 mA
    Vce Saturation (Max):
    200mV
    Grade:
    -
    Qualification:
    -
    Operating Temperature:
    -30°C ~ 100°C
    Mounting Type:
    Through Hole
    Supplier Device Package:
    4-DIP
    Datasheet:
    ICMILES ELECTRONICS LIMITEDAB814B.pdf
