FETs, MOSFETs
| 制造商 | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部重置
应用所有
结果:
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRFR110ATMN-CHANNEL POWER MOSFET Fairchild Semiconductor |
4,197 | - |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 4.7A (Ta) | 10V | 400mOhm @ 2.35A, 10V | 4V @ 250µA | 12 nC @ 10 V | ±20V | 240 pF @ 25 V | - | 2.5W (Ta), 20W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DPAK |
|
|
SFR2955TFP-CHANNEL POWER MOSFET Fairchild Semiconductor |
2,000 | - |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Bulk | Active | P-Channel | MOSFET (Metal Oxide) | 60 V | 7.6A (Tc) | 10V | 300mOhm @ 3.8A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±20V | 600 pF @ 25 V | - | 2.5W (Ta), 32W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
FDFMA3P029ZMOSFET P-CH 30V 3.3A 6MICROFET Fairchild Semiconductor |
1,964 | - |
|
Datasheet |
PowerTrench® | 6-WDFN Exposed Pad | Bulk | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 3.3A (Ta) | - | 87mOhm @ 3.3A, 10V | 3V @ 250µA | 10 nC @ 10 V | - | 435 pF @ 15 V | Schottky Diode (Isolated) | 1.4W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 6-MLP (2x2) |
|
|
IRFW820BTMN-CHANNEL POWER MOSFET Fairchild Semiconductor |
1,574 | - |
|
Datasheet |
- | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 2.5A (Tc) | 10V | 2.6Ohm @ 1.25A, 10V | 4V @ 250µA | 18 nC @ 10 V | ±30V | 610 pF @ 25 V | - | 3.13W (Ta), 49W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
SI4835DYP-CHANNEL MOSFET Fairchild Semiconductor |
1,298 | - |
|
Datasheet |
PowerTrench® | 8-SOIC (0.154", 3.90mm Width) | Bulk | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 8.8A (Ta) | 4.5V, 10V | 20mOhm @ 8.8A, 10V | 3V @ 250µA | 27 nC @ 10 V | ±25V | 1680 pF @ 15 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOIC |
|
|
HUFA76409D3SMOSFET N-CH 60V 18A TO252AA Fairchild Semiconductor |
1,222 | - |
|
Datasheet |
UltraFET™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 18A (Tc) | 4.5V, 10V | 63mOhm @ 18A, 10V | 3V @ 250µA | 15 nC @ 10 V | ±16V | 485 pF @ 25 V | - | 49W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
FDMS7698POWER FIELD-EFFECT TRANSISTOR, 1 Fairchild Semiconductor |
7,000 | - |
|
Datasheet |
PowerTrench® | 8-PowerTDFN | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 13.5A (Ta), 22A (Tc) | 4.5V, 10V | 10mOhm @ 13.5A, 10V | 3V @ 250µA | 24 nC @ 10 V | ±20V | 1605 pF @ 15 V | - | 2.5W (Ta), 29W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-PQFN (5x6) |
|
FDS6690A-NBNP006SINGLE N-CHANNEL, LOGIC LEVEL, P Fairchild Semiconductor |
5,311 | - |
|
Datasheet |
PowerTrench® | 8-SOIC (0.154", 3.90mm Width) | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 12.5mOhm @ 11A, 10V | 3V @ 250µA | 16 nC @ 5 V | ±20V | 1205 pF @ 15 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOIC |
|
FDFS2P753ZMOSFET P-CH 30V 3A 8SOIC Fairchild Semiconductor |
389,380 | - |
|
Datasheet |
PowerTrench® | 8-SOIC (0.154", 3.90mm Width) | Bulk | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 3A (Ta) | - | 115mOhm @ 3A, 10V | 3V @ 250µA | 9.3 nC @ 10 V | ±25V | 455 pF @ 10 V | Schottky Diode (Isolated) | 1.6W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOIC |
|
ISL9N312AD3N-CHANNEL POWER MOSFET Fairchild Semiconductor |
209,433 | - |
|
Datasheet |
UltraFET® | TO-251-3 Short Leads, IPAK, TO-251AA | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 50A (Tc) | 4.5V, 10V | 12mOhm @ 50A, 10V | 3V @ 250µA | 38 nC @ 10 V | ±20V | 1450 pF @ 15 V | - | 75W (Ta) | -55°C ~ 175°C (TJ) | - | - | Through Hole | IPAK |
