Balun
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Frequency Range | Impedance - Unbalanced/Balanced | Phase Difference | Insertion Loss (Max) | Return Loss (Min) | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TC4-19G2+1:4 CORE & WIRE TRANSFORMER, 10 |
3,364 |
|
Datasheet |
- | 5-SMD Module | Tape & Reel (TR) | Active | 10MHz ~ 1.9GHz | 1:4 | 6° | 3dB | 7.01dB | Surface Mount |
|
MTX2-143+1:2 MMIC TRANSFORMER, 5500 - 135 |
579 |
|
Datasheet |
- | 12-VQFN Exposed Pad | Tape & Reel (TR) | Active | 5.5GHz ~ 13.5GHz | 1:2 | 8° | 2.5dB | 7.87dB | Surface Mount |
|
B0110E50200AHFBALUN 50MHZ-1.45GHZ 50/200 1008 |
1,874 |
|
Datasheet |
Xinger® | 1008 (2520 Metric) | Tape & Reel (TR) | Active | 50MHz ~ 1.45GHz | 50 / 200Ohm | 180° | 2.5dB | 9.8dB | Surface Mount |
|
TCW2-2700+1:2 LTCC TRANSFORMER, 500 - 2700 |
1,612 |
|
Datasheet |
- | 0603 (1608 Metric), 6 PC Pad | Tape & Reel (TR) | Active | 500MHz ~ 2.7GHz | 1:2 | 19° | 1.7dB | 9.5dB | Surface Mount |
|
TTC1-33W+1:1 CORE & WIRE TRANSFORMER, 4.5 |
3,928 |
|
Datasheet |
- | 5-SMD Module | Tape & Reel (TR) | Active | 4.5MHz ~ 3GHz | 50 / 50Ohm | 4° | 3.3dB | 8.4dB | Surface Mount |
|
TC1.5-1+1:1.5 CORE & WIRE TRANSFORMER, 0 |
2,370 |
|
Datasheet |
- | 5-SMD Module | Tape & Reel (TR) | Active | 500kHz ~ 2.2GHz | 1:1.5 | - | 3dB | 9.3dB | Surface Mount |
|
TC1.5-1X+1:1.5 CORE & WIRE TRANSFORMER, 0 |
2,217 |
|
Datasheet |
- | 5-SMD Module | Tape & Reel (TR) | Active | 500kHz ~ 2.2GHz | 1:1.5 | - | 3dB | 9.3dB | Surface Mount |
|
TCM2-33X+1:2 CORE & WIRE TRANSFORMER, 30 |
1,831 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 30MHz ~ 3GHz | 1:2 | 4° | 3dB | 18.11dB | Surface Mount |
|
TRS2-252+1:2 CORE & WIRE TRANSFORMER, 4 - |
818 |
|
Datasheet |
- | 6-SMD, No Lead | Tape & Reel (TR) | Active | 4MHz ~ 2.5GHz | 1:2 | - | 3dB | 17.37dB | Surface Mount |
|
|
TC4-1WG2+1:4 CORE & WIRE TRANSFORMER, 3 - |
799 |
|
Datasheet |
- | 5-SMD Module | Tape & Reel (TR) | Active | 3MHz ~ 800MHz | 1:4 | - | 3dB | 9.07dB | Surface Mount |
|
|
TC1.33-282+1:1.33 CORE & WIRE TRANSFORMER, |
1,978 |
|
Datasheet |
- | 4-SMD, Flat Leads | Tape & Reel (TR) | Active | 5MHz ~ 2.8GHz | 1:1.3 | 6° | 3dB | 13.83dB | Surface Mount |
|
ADT1.5-122+1:1.5 CORE & WIRE TRANSFORMER, 2 |
1,858 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 20MHz ~ 1.2GHz | 1:1.5 | 1.2° | 2.0dB | 11.92dB | Surface Mount |
|
|
ADT1.5-1+1:1.5 CORE & WIRE TRANSFORMER, 0 |
1,228 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 500kHz ~ 650MHz | 1:1.5 | - | 3dB | 9.09dB | Surface Mount |
|
|
TCW2-722+RF XFMR / SURF MT / ROHS |
2,462 |
|
Datasheet |
- | 0603 (1608 Metric), 6 PC Pad | Tape & Reel (TR) | Active | 2.4GHz ~ 7.125GHz | 1:2 | 15° | 1.9dB | 12dB | Surface Mount |
|
MABA-011100BALUN,1:2TXLINE,20-4000MHZ,CERAM |
1,357 |
|
Datasheet |
- | 6-SMD Module | Tape & Reel (TR) | Active | 20MHz ~ 4GHz | 1:2 | 7° ±15 | 2.0dB | 7dB | Surface Mount |
|
|
ADT9-1T+1:9 CORE & WIRE TRANSFORMER, 1 - |
1,000 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 1MHz ~ 250MHz | 1:9 | 1° | 2.0dB | 8.05dB | Surface Mount |
|
TRS1.5-182+1:1.5 CORE & WIRE TRANSFORMER, 1 |
356 |
|
Datasheet |
- | 4-SMD Module | Tape & Reel (TR) | Active | 10MHz ~ 1.8GHz | 1.5:1 | 7.5° | 2.8dB | 14dB | Surface Mount |
|
ADTT4-1+1:4 CORE & WIRE TRANSFORMER, 0.2 |
312 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 200kHz ~ 120MHz | 1:4 | 3° | 1.0dB | 17.71dB | Surface Mount |
|
|
T2-1T-KK81+1:2 XFMR, 0.07 - 200 MHZ, 50 |
714 |
|
Datasheet |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | 70kHz ~ 200MHz | 1:2 | - | 3.0dB | - | Surface Mount |
|
ADT8-1T+1:8 CORE & WIRE TRANSFORMER, 0.1 |
616 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | 100kHz ~ 130MHz | 1:8 | 2° | 3dB | 7.87dB | Surface Mount |
